HT1B (formerly HT35A) - DC Current Transformers / Transducers - Torroidal

Features

  • DC current transformer/transducer - to measure DC current and deliver a proportional DC analogue output
  • DC Current measurement, Hall Effect
  • 35mm (HT1B) internal aperture
  • Current transformer with built in transducer
  • Measured current up to 1000A dc
  • AC or DC supply voltage

Details

A torroidal transducer that operates on the hall effect principle to measure DC current and provide a proportional analogue output.

The HT1B has a 35mm diameter aperture, through which the conductor is passed. An auxiliary supply is required. Where current output is specified, a dipswitch allows the user to select either 0…20mA or 4…20mA. Both models may be mounted on DIN rail by means of an optional clip.

Downloads

Files

HT1B Data Sheet HT1B Data Sheet NT500-04
HT1B Manual HT1B Manual 10780501 09-04
Product Name / Options Price (ex VAT)
HT1BC153T (150A 10VDC 20-150Vdc/40-60Vac) Call for Prices

HT1BC4042 (400A 4-20mA 115Vac) Call for Prices

HT1BC404T (400A 0-20MA 20-150VDC) Call for Prices

HT1BC103T (100A 10VDC 20-150Vdc/40-60Vac) Call for Prices

HT1BC1042 (100A 4-20mA 115Vac) Call for Prices

HT1BC304T (300A 4-20mA 20-150Vdc/40-60Vac) Call for Prices

HT1BC204T (200A 4-20mA 20-150Vdc) Call for Prices

HT1BC403T (400A 0-10V 20-150Vdc/40-60Vac) Call for Prices

HT1BC2042 (200A 4-20mA 115Vac) Call for Prices

HT1BC104T (100A 4-20mA 20-150Vdc/40-60Vac) Call for Prices
