Ultra-compact, very thin, plugs directly into the PLC
Process management, sorting… etc.
MODBUS RS485 (RTU) or RS232 (ASCII) network
Life cycle : 20 years
Max activation distance : up to 45mm
Contact : 1 x strobe PNP /1 RS485 (base + 485) or RS232 (base + 232)
Detection encoding : infinite
Indicator : LED indicates code recognition
Reset : automatic
Mounting : M30 nut provided
Mounting position : 1
Material : TR90UV
Electrical connection : screwless terminal
Sealing : IP 67
Temperature : -20°C…+60°C
Marking : screen printing
Options : - Stainless steel badge holder: AXKEF/CARD HOLDER
- badge nail, screw, plate screw, key chain, card ... etc.
