  • IME RQ48FI Analogue Frequency Meters with built-in transducer 48x48mm

More Views

IME RQ48FI Analogue Frequency Meters with built-in transducer 48x48mm

Features

  • Direct indication of input frequency
  • Direct connection
  • Voltage 100...440V
  • Moving coil equipment
  • Scale length 90°
  • Accuracy cl.0,5 (cl.1 45...65Hz)
  • Rating : protection IP52 front protection, IP20 terminal protection with terminal cover

Details

Direct indication of input frequency Direct connection Voltage 100.....440V Moving coil equipment Scale Length 90° Accuracy cl 0.5 (cl 1 45...65Hz) Additional Analogue Instrument Optional Extras ?? Tropicalisation IP54 Front Protection

Additional Information

Manufacturer IME (BTicino)

Downloads

Product Name / Options Price (ex VAT)
IME RQ48FI 45...55Hz AN1711 100V Analogue Frequency Meters Call for Prices
AN1712 - RQ48FI 45-55Hz 100-115V Call for Prices
AN1713 - RQ48FI 45-55Hz 230-240V Call for Prices
IME RQ48FI 45...55Hz AN1714 400-415V Analogue Frequency Meters Call for Prices
AN1715 - RQ48FI 45-55Hz 440V Call for Prices
IME RQ48FI 45...65Hz AN1721 100V Analogue Frequency Meters Call for Prices
AN1722 - RQ48FI 45-65Hz 100-115V Call for Prices
AN1723 - RQ48FI 45-65Hz 230-240V Call for Prices
IME RQ48FI 45...65Hz AN1724 400-415V Analogue Frequency Meters Call for Prices
AN1725 - RQ48FI 45-65Hz 440V Call for Prices
IME RQ48FI 55...65Hz AN1731 100V Analogue Frequency Meters Call for Prices
IME RQ48FI 55...65Hz AN1732 100-115V Analogue Frequency Meters Call for Prices
IME RQ48FI 55...65Hz AN1733 230-240V Analogue Frequency Meters Call for Prices
IME RQ48FI 55...65Hz AN1734 400-415V Analogue Frequency Meters Call for Prices
IME RQ48FI 55...65Hz AN1735 440V Analogue Frequency Meters Call for Prices
Add Optional Analogue Instrument Option Extra - Tropicalisation Call for Prices
Add Optional Analogue Instrument Option Extra - IP54 Protection Call for Prices
