RFID sensor with 16 million codes
Lock control and "burglar" alarm
Supervision, traceability via PC, RS485 network and output contacts
Life cycle : 20 years
Max activation distance : up to 45mm
Contact/diagnostics : 1 x 1.8A PNP timed 5s/2 x 100mA PNP
Alarm 1 (120s failure to close) and 2 (30s breaking open)
Detection encoding : inviolable multicode
Indicator: LED indicates code recognition
Reset : automatic
Attachment : 4 tamper-proof M4 screws (in base option: BH4)
Mounting position : 1
Material : POLYCARBONATE
Electrical Connection : 50cm PUR cable with M12 connector
Sealing : IP 67
Temperature : -20°C…+60°C
Marking : pad printing + serial number for traceability
Options : - Software for real-time monitoring with openings traceability via PC (ref MDB13-SP.)
- Software programming of badges and network configuration (ref MDB13-PR.)
- Automatic network connection (LKS485): up to 8 cascading boxes and 4 readers per box or 32 readers. Individual contact outputs on each box
- badge nail, screw, plate screw, key chain, card… etc.
Application example : access to luxury showcases with lock control and traceability
