Our NEW easywire® three-phase mini split-core current transformers combine non-intrusive installation, compactness for tight spaces, and synchronised 3-phase monitoring. They have been specifically designed for retrofitting into existing electrical systems without the need to shut down power.

The split-core design allows the current transformers to be opened and clamped directly around an existing conductor. This eliminates the need to disconnect wiring or halt operations and makes them ideal for adding monitoring to existing commercial or industrial panels where the space is limited.

The quick ’snap-on’ installation coupled with the significant time saving already offered by our easywire system, significantly reduces labour costs compared to the installation of standard solid-core alternatives.

All our easywire® current transformers include built-in over-voltage protection circuits to protect technicians and equipment, especially if the secondary is left open under load.

They are equally suited for temporary energy audits, troubleshooting, and permanent sub-metering applications.

Call us now for our great launch prices!

See the products - Click Here

easywire® - the original and still the best...

This dairy farm operates 24hrs a day, 365 days a year and was predominately looking to maximise its on-site electricity generation to provide cost savings as well as reducing its impact on the environment. Plus reducing their exported energy by storing it for high demand periods.

Additionally, they wanted to charge from the grid overnight and then run the early milking shift from BESS, taking advantage of the cheaper tariff.

See how this was achieved by downloading the Case Study now...

Download Case Study - (611KB)

October Update - Now includes High Accuracy Current Transformers.

Download your copy now...

Our money saving easywire system of energy meters and current transformers coupled with our cloud based rayleighconnect remote monitoring and control software are the perfect energy management ecosystem.

Call us now to for more information - +44(0)1245 428 500

In the modern era of smart technology, the integration of Building Management Systems (BMS) such as Rayleigh Instruments rayleighconnect™ has revolutionized the way we interact with and manage our built environments. A BMS, also known as a Building Automation System (BAS), encompasses a network of hardware and software that monitors and controls a building's mechanical and electrical systems. From heating, ventilation, and air conditioning (HVAC) to lighting, security, and beyond, BMS offers a plethora of benefits that enhance both operational efficiency and occupant comfort.

Optimized Energy Consumption: One of the most significant advantages of implementing a BMS is its ability to optimize energy consumption within a building. By continuously monitoring energy usage and environmental conditions, the system can automatically adjust settings to minimize waste without compromising comfort. For instance, during periods of low occupancy, the BMS can regulate HVAC and lighting systems to operate at reduced levels, resulting in substantial energy savings and lower utility bills.

Enhanced Comfort and Productivity: Comfortable indoor environments are crucial for occupant satisfaction and productivity. BMS allows for precise control over temperature, humidity, and lighting levels, creating optimal conditions tailored to the preferences of building occupants. With features like zoned temperature control and automated lighting adjustments based on natural light levels, BMS ensures a pleasant and conducive workspace that promotes productivity and well-being.

Proactive Maintenance and Fault Detection: BMS continuously monitors the performance of building systems and equipment, allowing for early detection of issues and potential faults. By analyzing data and identifying patterns, the system can predict maintenance needs and schedule repairs before problems escalate. This proactive approach not only reduces downtime and maintenance costs but also prolongs the lifespan of equipment, ensuring reliable operation in the long run.

Streamlined Operations and Management: Centralized control and monitoring capabilities provided by BMS streamline building operations and management. Facility managers gain real-time visibility into system performance and can remotely adjust settings or troubleshoot issues from a single interface. This level of control not only improves operational efficiency but also enables quick response to changing conditions and emergencies, enhancing overall safety and security.

Compliance and Sustainability: Meeting regulatory requirements and achieving sustainability goals are top priorities for modern buildings. BMS facilitates compliance with building codes and standards by ensuring adherence to environmental regulations and energy efficiency guidelines. Furthermore, by optimizing energy usage and reducing carbon footprint, BMS plays a vital role in advancing sustainability initiatives and minimizing the environmental impact of buildings.

Data-driven Insights for Decision Making: BMS generates vast amounts of data regarding building performance, energy consumption, and occupant behaviour. By leveraging advanced analytics and machine learning algorithms, this data can provide valuable insights that inform strategic decision-making processes. From identifying opportunities for further optimization to predicting future trends and requirements, data-driven intelligence derived from BMS empowers stakeholders to make informed choices that drive efficiency and innovation.

Building Management Systems offer a myriad of benefits that encompass efficiency, comfort, sustainability, and operational excellence. By harnessing the power of technology to automate and optimize building operations, BMS not only reduces costs and enhances performance but also creates healthier, more enjoyable environments for occupants. As buildings become increasingly interconnected and intelligent, the role of BMS in shaping the future of the built environment cannot be overstated.

With the rayleighconnect™ cloud-based Building Management System you will have a scalable system to gain insight and manage all of your building's energy systems.

Call us now to arrange your free online demonstration - +44(0)1245 428 500

In the global pursuit of sustainable energy solutions, grid-tied inverters have emerged as a crucial component in maximizing the efficiency and effectiveness of renewable energy systems. These innovative devices play a pivotal role in converting the direct current (DC) electricity generated by solar panels (or wind turbines) into alternating current (AC) electricity compatible with the power grid. As the world transitions towards a cleaner and greener future, the benefits of grid-tied inverters are becoming increasingly evident.

1. Seamless Integration with the Grid:

One of the primary advantages of grid-tied inverters is their ability to seamlessly integrate renewable energy systems with the existing power grid. Unlike off-grid systems that require battery storage for energy storage, grid-tied inverters allow surplus electricity generated by solar panels or wind turbines to be fed directly into the grid. This not only ensures an uninterrupted power supply but also enables renewable energy producers to benefit from net metering programs, where excess electricity can be credited or sold back to the utility company.

2. Increased Energy Efficiency:

Grid-tied inverters are designed to optimize energy production by continuously adjusting the output voltage and frequency to match grid requirements. This dynamic response ensures maximum energy efficiency and minimizes losses during the conversion process. Furthermore, grid-tied systems can take advantage of grid power during periods of low renewable energy generation, further enhancing overall energy efficiency and reliability.

3. Cost-Effectiveness and Affordability:

Compared to off-grid systems that require expensive battery storage solutions, grid-tied inverters offer a more cost-effective approach to renewable energy integration. By eliminating the need for batteries, grid-tied systems reduce upfront installation costs and ongoing maintenance expenses, making renewable energy more accessible and affordable for homeowners, businesses, and communities.

4. Flexibility and Scalability:

Grid-tied inverters provide flexibility and scalability, allowing renewable energy systems to be tailored to specific needs and requirements. Whether it's a small residential solar array or a large-scale commercial wind farm, grid-tied inverters can be easily integrated into systems of any size. Additionally, modular design and expandability options enable easy upgrades and additions as energy needs evolve over time.

5. Environmental Benefits:

By harnessing renewable energy sources such as solar and wind power, grid-tied inverters contribute to reducing greenhouse gas emissions and mitigating climate change. Unlike fossil fuel-based power generation, renewable energy systems powered by grid-tied inverters produce clean, renewable electricity without emitting harmful pollutants or greenhouse gases. This not only helps combat air pollution but also promotes environmental sustainability and conservation of natural resources.

6. Grid Stability and Reliability:

Grid-tied inverters play a crucial role in maintaining grid stability and reliability by balancing supply and demand in real-time. Through advanced monitoring and control capabilities, these inverters ensure smooth integration of renewable energy into the grid without compromising system stability or causing disruptions. Moreover, grid-tied systems can provide ancillary services such as frequency regulation and voltage control, further enhancing grid resilience and reliability.

In conclusion, grid-tied inverters represent a cornerstone of modern renewable energy systems, offering a host of benefits ranging from increased energy efficiency and cost-effectiveness to environmental sustainability and grid reliability. As the world transitions towards a clean energy future, the widespread adoption of grid-tied inverters will play a pivotal role in accelerating the transition and unlocking the full potential of renewable energy resources.

Rayleigh Instruments offers a growing range of grid-tied inverters, both Single-Phase and Three-Phase for domestic and commercial Solar PV applications.

Our new Rayleigh Instruments PV Inverters and Batteries Overview brochure 2023 is now available as a PDF for download.

This brochure contains our single and three-phase inverters, Grid-Tied Inverters, Hybrid Inverters and Battery solutions for home energy storage, commercial energy storage and solar PV installations as of May 2023.

Single-Phase Invertes are available as 1.1kW, 1.6kW, 2.2kW, 2.7kW, 3kW, 3.6kW, 3.6kW, 4kW, 4.6kW, 5kW and 6kW AC output.

Three-Phase Inverters are available as 4kW, 5kW, 6kW, 8kW, 10kW, 12kW, 15kW, 17kW, 20kW, 25kW, 30kW, 36kW, 40kW, 50kW, 60kW, 70kW, 75kW, 80kW, 120kW and 150kW AC output versions.

Download your copy now...

To Register and for full details about the event, visit the CEFLIVE23 webpage:-
Click Here for the CEFLIVE2023 Website

In 2012 Rayleigh Instruments patented and launched the groundbreaking Easywire range.

Further Information



For products, click here : easywire® Products



To make an enquiry, click here : easywire® enquiry

Please take a moment to watch the above movie

We are complying with all government recommended COVID-19 precautions, such as handwashing and distancing. The safety of our staff and customers remain our top priority.

AquAid has built more than 8,000 Elephant Pumps across many parts of Malawi, Mozambique, Liberia and Zimbabwe; and have donated more than £16 million to charity and we wish them every success with all their aid projects.



As standard, the RI-F220 comes with pulse output and Modbus RS485 communication and has all the usual specifications.

• DIN 72 panel-mounted
• -/1A or -/5A current transformer input
• Single-phase or three-phase network compatible
• Programmable voltage and current transformer ratio
• Active energy class 1
• Reactive energy class 2
• True RMS measurement
• High definition white backlit LCD display
• Simple programming and operation
• Pulse output and Modbus communication
• Auto and manual page scrolling

For more information check out the RI-F220 product page HERE .

Download your copy now...

Rayleigh Instruments would like to thank all our customers and partners for visiting our stand at Hannover Messe, and for pushing us to develop new and innovative products for our industry.

Yet again the Hannover Messe proved a great success for Rayleigh Instruments and gave us an opportunity to showcase our extensive range of products. The main talking point of this years exhibition was the announcement of our easywire® DIN Rail meters becoming MID approved for billing applications.

Check out the links below for information on some of this years talking points.

Click above to see all the features of the MID approved easywire® meter offerings including the Dual load RI-D360 (thats 2x CT inputs into 1 meter - and MID certified!)

Three MID certified meters, duel and quad load meters and 5 three-phase current transformer frame sizes are available in the range.

Download your copy now...

The two versions available are; the Nemo 96 HDLe panel meter, with plug in modules that offer a wide variety of communication outputs and the Nemo D4-Le DIN Rail mounting version, with built in Pulse, Modbus or BACNET communication protocols.

A wide 4-line backlit display provides a clear view of the main electrical parameters in addition to the bi-directional active (kWh) and reactive (kvarh) energy counting in cl. 1 according to EN / IEC 61557-12, THD harmonic distortion for current and voltage up to the 50th order and crest factor.

The associated Rogowski coils are available in lengths of 80mm, 142mm and 190mm as standard with primary current measuring of 20A to 5000A and are directly connected to the multifunction meter(s) without the need of additional transducers.

For prices and availability please call our sales office now on 01245 428 500

Chris Jones, sustainability manager of University of Bristol, explains how Rayleigh Instruments is helping with the university’s future sustainability.

What challenges does the University of Bristol currently face?

Over the last decade, The University of Bristol has grown 30% in size, population and infrastructure and is set to continue growing over the coming years. Sustainability is one of our main focuses, with it featuring on the university’s strategy plan; we aim to be completely net carbon neutral by 2030 and are on target to meet this.

The campus currently consists of over 300 buildings of all types, from farms to laboratories to offices to hospitals. These are spread across Bristol city centre, Stoke Bishop, Langford and Clifton and, as a university, we have the highest proportion of listed buildings within the sector.

The scale and variety of our campuses make it difficult to differentiate energy usage. The university’s theatres, offices, laboratories, student housing, and more were all measured on one meter, making it challenging to track what energy was being used where.

We tried sub-metering but this presented us with new issues. Many sub-meter systems used price per point, meaning we were paying a set amount per year which resulted in us self-censoring our coverage. We noticed we were focusing our attention on the largest metered buildings, ruling out 60% of our unmetered buildings, limiting our potential energy saving options.

Our aim was to collect as much information as possible and to do this we focused our budget on the installation of meters across every university building. This is where Rayleigh Instruments came in.

How did you discover Rayleigh Instruments?

We held a mini competition on metering and sub-metering and Rayleigh Instruments came in at the most cost effective. We have been working with Rayleigh Instruments since June 2010 and currently have 220 Rayleigh Connect systems installed and networked within our buildings.

Our partnership is mutually beneficial, the university’s knowledge of both the sector and the product meant we could take a beta style product and suggest improvements to Rayleigh Instruments. In our research, many of our buildings are used as testing ground and we have used the Rayleigh Connect system to provide data to our academic researchers.

What practical benefits has Rayleigh Instruments provided?

Firstly, using the Rayleigh Connect system is very cost effective. They run using a cloud-based software that records the energy through the sub-meters and allows us to monitor the data on phones, laptops, tablets, wherever we are. We see the savings made by using this software. Analysing the data showed us that much of our electrical energy is going on moving air, primarily through our highly serviced areas, such as our laboratories. This is hugely expensive as the air moves through the lab and is dissipated, so all the money spent on heating is wasted.

How has Rayleigh Connect helped with data control and research?

Sub-metering turns anecdote into fact, meaning our predications about the universities energy usage can be proven, or disproven, using the data collected the sub meters provide. They enable us to retrieve data from all our building via ethernet or sim card, meaning substations that without network capability can still have their data collected, downloaded and analysed by us and Bristol academics.

The system allows us complete access to the data, which we then download onto Systemlink, a data validation software which we use to authorise our fiscal metering and reconcile our data. This can then be used for academic purposes to study energy usage and shared with students, staff and faculties.

How successful has this data collection been?

It has been hugely successful, so much so we have been awarded a grant from the UK Collaboratorium for Research on Infrastructure and Cities (UKCRIC), a national research project that aims to address unsustainability used by services in the national infrastructure. Our research, alongside our connections with Bristol City Council and the Bristol Is Open project, has granted us part of this 500-million-pound project, allowing us to increase our research on energy efficiency.

How much has Rayleigh Instruments saved the University?

The university uses £6m worth of electricity and £2m of gas per year, a huge amount that is only set to increase due to rising electricity prices. Rayleigh Instruments’ metering systems have enabled us to make sense of where our energy goes and has saved the university a huge amount. Over the last seven years of working with Rayleigh Instruments we have implemented measures that have saved £1.7m a year against business as usual.

How has Rayleigh Instruments helped identify and resolve issues of energy usage?

We can save considerable amounts, more than we ever spend on meters. The meters help with this as it tells us where our consumption is high and verifies where we have avoided it.

Rayleigh Instruments also helps with high tariff avoidance. Although we pay less than your average household consumer, we have many additional charges and some of them only apply at certain times of the day. However, we are given full visibility of these charges, meaning we can avoid peak usage times, saving both money and energy. For example, energy costs in the South West peak between 5pm-7pm - everyone is using energy between these times and to encourage users to switch off there are large increases in price.

Using Rayleigh Instruments, we can identify where energy is used and when. We can’t switch off experiments or students’ TV’s in these peak times simply to save money, but we can ensure that any electrical water tanks are already fully heated.

What are the university’s future goals regarding sustainability?

Despite the university’s increasing size, we have decreased our energy usage. We plan to continue this, with a long-term goal of making the university net carbon neutral by 2030. This goal affects every decision we make, putting sustainability at the focus of the university’s future.

What is the future for Rayleigh Instruments and Bristol University’s working partnership?

We are constantly working closely with Rayleigh Instruments to make new opportunities and technology to increase sustainability for, not only the university, but also for wider use. Our wide range of buildings have enabled us to spot potential problems and developmental areas, which we then forward to Rayleigh Instruments for a solution. For example, we are currently exploring how we can bring other Modbus non-metering equipment onto the system, as we have done with our solar panel invertors. This means if we can identify the register, Rayleigh Instruments will programme it in. This partnership promises a bright future, not only for the sustainability of Bristol University, but also the sustainability of all commercial buildings.

We would like to thank all our customers, dealers, agents and other visitors for visiting our stand at this years Hannover Messe. We hope you thoroughly enjoyed your visit and our hospitality.

The Exhibition was a great success for Rayleigh instruments and gave us the opportunity to showcase all our successful collections. It also gave us the opportunity to reveal some of our new additions which generated great interest.

Please do not hesitate to contact us at exports@rayleigh.com for any questions or feedback you may have following the exhibition.

We will be very happy to receive your enquiry and we hope you enjoyed your visit to us and the fair.

easywire® - MID Certified for Billing

With the arrival of our new MID Approved easywire Plug & Play meter the RI-F300 we are set to take the industry by storm. A unique concept that dramatically reduces the wiring/installation time of multifunction power meters and current transformers is now MID approved.

The huge savings are made possible due to the innovative design of both the current transformers and the meters, which allow plug in connectors to be used for both current and voltage input/output. An RJ45 lead is used for connecting between the three phase current transformer and meter, and 'readymade' plug in leads are used for the voltage input. With the RI-F300 easywire multifunction meter being MID approved our solution has the accuracy and quality required to be used for Billing Applications.

View the RI-F300 Product Page.

NEW Range of Current Transformers

One of the collections on show at this year’s fair was our extensive range on Current Transformers. On display we had a wide range of Single phase, three phase, split core and horizontal Current Transformers. For an overview of our CT range click on the Data Sheet Download link below.

Download the Current Transformers Overview PDF

MID Approved Multifunction Meters

With the new release of our MID approved DIN 96 panel mounting meter the RI-F100 and our DIN rail version RI-D140, our MID approved meter range was a big talking point at this years Hannover Messe.

RI-F100 and RI-D140 Features

• -/1A or -/5A current transformer input (MID on 5A Only)
• Programmable voltage and current transformer ratio
• True RMS measurement
• High definition white backlit LCD display
• MID B+D Certified
• Cost effective and accurate
• Simple programming and operation

View the RI-F100 Product Page.

View the RI-D140 Product Page.

Some of the industry’s biggest names visited the stand and commented on our success and ability to design new, innovative products and keep the costs down.

The products that stole the show were once again our “Easywire Metering” System which is designed to ensure a faster installation with minimal wiring errors and our New Rayleigh connect monitoring software which is user friendly and customizable to meet the customer’s specific requirements.

With our rapid growth in and outside of the UK we had a lot of interest from European countries to become a Rayleigh Instruments approved Distributor to promote our products worldwide.

If you are interested in becoming a Rayleigh approved distributor please contact Jamie Sales - j.sales@rayleigh.co.uk

The President of the United States Barack Obama and the German Chancellor Angela Merkel are due to open Hannover Messe 2016 which is the world's most important trade fair for industrial technology. The show runs from Monday, 25th to Friday, 29th April in Hanover Germany. President Obama is due to appear at the exhibitions official opening ceremony on Sunday, 24th April and is scheduled to accompany Merkel on the traditional opening tour on Monday morning. Approximately 5,000 companies from 70 countries will be exhibiting at Hannover this year making it a 'must visit' event.

Rayleigh Instruments are delighted to be exhibiting again at the exhibition after their very successful appearance last year. Rayleigh will again be showing their Cloud based remote monitoring, control and billing system rayleighconnect™ along with their fantastically successful easywire® system for the rapid wiring and installation of Multifunction Energy Meters and Three Phase Current Transformers - again both systems are expected to generate a tremendous amount of interest. They will also be showing a raft of brand new products at the show - watch this space!

rayleighconnect™ - the Remote Monitoring and Control Solution

Rayleigh Connect is a cloud based energy management and remote control software package. Users can access the software online from any terminal (PC, Ipad or smart phone) that has connection to the internet, or offline if required. Applications are also available for IPhone, IPad and Android devices.When used as an energy management metering solution it allows the user to record data from one up to 4096 electricity, gas, water, heat meters or temperature sensor. Any device with pulse outputs or RS485 modbus can be connected via an interface module. These devices then transmit the collected data to the software , at a selectable frequency from once per minute up to once per month. When used with MID approved energy meters the system can also be used for automatic remote billing (upgraded licence required).

Pictured above - rayleighconnect™ user configurable dashboard screens on various devices.

Save Time, Save Money with easywire®

UK and EU Patent Approved - more countries to come.

A unique concept that dramatically reduces the wiring/installation time of multifunction power meters and current transformers by 90% - the original and best.

These savings are made possible due to the innovative design of both the current transformers and the meters, which allow plug in connectors to be used for both current and voltage input/output. An RJ45 lead is used for connecting between the three phase current transformer and meter, and 'readymade' plug in leads are used for the voltage input

Why not come along and discover a host of product innovations and latest technology - get your FREE Ticket Here

You can find Rayleigh Instruments in Hall 12 Stand D29 - we look forward to seeing you.

Rayleigh Instruments appointed as a Channel Partners for ELSTER Electricity Meters.

Since October 2014, Rayleigh Instruments has grown into the largest stockist of ELSTER electricity meters supporting the UK market. We stock the complete range of domestic single phase, polyphase, AMR, Smart, commercial and industrial energy meters including the A100C, A1100DC, A1140, AS230 and A1700.

Click here to see our Elster Channel Partner partnership link.

A100C - The A100C family of domestic electronic single phase meters comply too DIN/BS specifications. The meter offers IrDA or IEC 62056-21 communications. This allows register values, security information etc to be read either optically or via a hard wired connection, making it ideal for AMR applications.

Click here for more details.

A1100 - The A1100 is ideally suited to domestic, commercial or light industrial polyphase metering applications and has the option of a liquid crystal display or mechanical register. It offers highly secure metering, with advanced security features and IrDA communications which makes it ideal for use in simple AMI applications.

Click here for more details.

AS230 - The AMI AS230 is a domestic Smart Meter which offers multi-tariff metering and flexible modular communications to interface directly to the utility via WAN or LAN and to connect to a consumer's Home Automation Network (HAN).

Click here for more details.

A1140 - The A1120/A1140 is designed to meet the changing needs of the electricity supply industry. The meter offers comprehensive tariff and security features and modular communications solutions, allowing easy integration into an AMR system.

Click here for more details.

A1700 - The A1700 offers outstanding measurement and complex tariff capability for industrial and commercial applications. Its modular design allows the addition of an input or output module and a communications module to be fitted securely underneath the terminal cover.

Click here for more details.

Our support of the Elster ranges incorporates :-

• On site troubleshooting
• Onsite installations
• Programming of meters in-house
• Next day delivery to UK mainland
• Full technical support

Click here to see all our Elster Products

City Electrical Factors have hosted their first wholesale electrical trade show. The event was held in Hall 9 at the NEC, Birmingham on Friday 19th June 2015. The CEF Live event hosted more than 40 industry leading manufacturers, with product learning seminars by industry experts as well as innovative product launches.

This event was a must for electrical contractors; architects; specifiers; public sector bodies and private sector Companies.

Rayleigh Instruments were delighted to be showing products at this inaugural event including their range of Elster kWh meters, Easywire meters and current transformers, their range of Elko and Datexel products along with Rayleigh energy meters and many of their stocked CT's.

We wish this event every success in the future.

HANNOVER MESSE 2015 is a huge Trade Show that was ceremoniously opened by the German Chancellor Angela Merkel, together with India’s Prime Minister Narendra Modi.

Among the products displayed by Rayleigh Instruments at the show was our Cloud Based Software 'Rayleigh Connect' and our Patented 'EasyWire' Metering System, both of which generated tremendous interest.

Rayleigh Connect - the Remote Monitoring and Control Solution

Rayleigh Connect is a cloud based energy management and remote control software package. Users can access the software online from any terminal (PC, Ipad or smart phone) that has connection to the internet, or offline if required. Applications are also available for IPhone, IPad and Android devices.When used as an energy management metering solution it allows the user to record data from one up to 4096 electricity, gas, water, heat meters or temperature sensor. Any device with pulse outputs or RS485 modbus can be connected via an interface module, such as 'Easy Control' GSM device (1-16 meters), 'Easy Control Expert GSM Device (1-128 meters), 'Easy Ethernet Device (1-510 meters) or other approved units. These devices then transmit the collected data to the software , at a selectable frequency from once per minute up to once per month.

Pictured above - Rayleigh Instruments Ryan Welshman demonstrates the user friendly interface of the rayleighconnect system and shows a graph illustrating the drop in output from a solar energy site during the recent solar eclipse.

Easywire = Save Time, Save Money...

UK and EU Patent Approved - more countries to come.

A unique concept that dramatically reduces the wiring/installation time of multifunction power meters and current transformers.

These savings are made possible due to the innovative design of both the current transformers and the meters, which allow plug in connectors to be used for both current and voltage input/output. An RJ45 lead is used for connecting between the three phase current transformer and meter, and 'readymade' plug in leads are used for the voltage input. The meters are provided with both input and output voltage connections which allows multiple meters to be powered from one supply.

Daisy-chain up to 32 Meters!... Power up to 32 Energy Meters from a single power source.

Power-up your meter... Plug the ready-made ‘supply’ lead connector into your meter. Connect the other, ferrule tipped, ends to the supply, not forgetting to use the correct fuses, and you’re done.

Connect your current transformer Plug one end of the RJ45 lead into the multifunction power meter and the other end into the three-phase current transformer and you’re done - it’s that simple.

More than one meter?... Plug the ready-made ‘linking’ lead connector from your first meter to your secondThis system is safer than using traditional current transformers because Easywire transformers incorporate the resistive shunts usually located within the power meter. This means that the secondaries are always loaded, therefore eliminating the possibility of dangerously high voltages developing during open circuit conditions. This allows the meter to current transformer to be disconnected without the need for secondary shorting terminals, again saving money and reducing downtime.

Rayleigh Instruments were proud to have exhibited at this fantastic show, and will look be be present again in 2016 - Thank you to all those who attended - see you next year!

Rayleigh Instruments are exhibiting at Hannover Messe the Worlds biggest industrial fair. You can find us in:-

Hall 12 Stand No. B33.

13th to 17th April 2015
